Summary
Overview
The SV-8150.HD is an ultra-slim universal 4.3 color LCD monitor. This high-definition color monitor will give the driver the best crystal-clear image whether it is being used as a rear view camera monitor or other video source.
This monitor offers 2 video inputs, 1 for reverse camera that offers auto-switching when the vehicle is placed into revers and a second that will show when not in reverse. The multi-mount will allow the monitor to be mounted to either the dashboard or the windshield. The compact design will ensure that the monitor takes nothing away from the vehicles interior and is perfect for those vehicle with limited dash space.
Specifications
Display Type:HD Digital Color LCD
Screen Size: 4.3"
Display Resolution: 1200 680
Video System: NTSC / PAL
Backlight: LED
Touchscreen: No
Audio In/Out: No
Normal/Reverse Image: No
Mounting Type: Universal
Video Input: (2) RCA 1.0Vp-p Composite (75 Ohm load)
Dimensions: 2"(L) 4"(W) 1"(D)
Operating Temperature: -4F - 140F (-20C - 60C)
Power Source: DC 12V
Power Consumption: 0.6W
Waterproof: No
